Asus  |  SKU: 90MB1HE0-M0EAY0
27% off

Asus TUF Gaming B760M-PLUS WIFI II Motherboard, LGA1700 Socket, mATX Form Factor, DDR5, PCIe 5.0 With SafeSlot Core+, Wi-Fi 6E, Bluetooth v5.3, HDMI, DisplayPort, Realtek 2.5Gb Ethernet, TUF LANGuard, Aura Sync, 1 Year Warranty | 90MB1HE0-M0EAY0

Sale price AED 730.00 Regular price AED 999.00
Inclusive VAT

  • Socket: LGA1700
  • Chipset: Intel B760
  • Processor Support: Intel 14th, 13th, and 12th Gen Core / Pentium / Celeron Processors
  • Ram: DDR5
  • Max Ram: 192GB (Supports up to 7800+ MT/s OC)
  • Wireless: Wi-Fi 6E, Bluetooth v5.3
  • Ethernet: Realtek 2.5Gb (TUF LANGuard)
  • Form Factor: m-ATX
  • PCIe x 16: 1 x PCIe 5.0
  • 1 Year Warranty

Specifications

  • Wireless
    Wi-Fi 6E + Bluetooth® v5.3
  • Chipset
    Intel® B760 Chipset
  • Internal I/O Connectors
    Fan and Cooling related:
    1 x 4-pin CPU Fan header
    1 x 4-pin CPU OPT Fan header
    1 x 4-pin AIO Pump header
    3 x 4-pin Chassis Fan headers
    Power related:
    1 x 24-pin Main Power connector
    2 x 8-pin +12V Power connectors
    Storage related:
    3 x M.2 slots (Key M)
    4 x SATA 6Gb/s ports
    USB:
    1 x USB 10Gbps connector (supports USB Type-C® )
    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    3 x USB 2.0 headers support 5 additional USB 2.0 ports
    Miscellaneous:
    3 x Addressable Gen 2 headers
    1 x Clear CMOS header
    1 x Front Panel Audio header (AAFP)
    1 x 20-3 pin System Panel header with Chassis intrude function
    1 x Thunderbolt™ (USB4®) header
  • Graphics Device
    1 x DisplayPort
    1 x HDMI™ port
  • Expansion Slots
    Expansion Slots:
    1 x PCIe 5.0 x16 slot
    1 x PCIe 4.0 x4 slot
    1 x PCIe 3.0 x1 slot
    Storage:
    3 x M.2 slots
    4 x SATA 6Gb/s ports
  • Memory Slots Support
    4 x DIMM slots, Max. 192GB, DDR5 7800+
    Dual Channel Memory Architecture
    Supports Intel® Extreme Memory Profile (XMP)
  • Sound
    Realtek 7.1 Surround Sound High Definition Audio CODEC
    Audio Features:
    - Audio Shielding
    - Rear optical S/PDIF out port
    - Premium audio capacitors
    - Dedicated audio PCB layers
  • USB
    Rear USB:
    1 x USB 20Gbps port (1 x USB Type-C®)
    1 x USB 10Gbps port (1 x Type-A)
    2 x USB 5Gbps ports (2 x Type-A)
    4 x USB 2.0 ports (4 x Type-A)
    Front USB:
    1 x USB 10Gbps connector (supports USB Type-C®)
    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    3 x USB 2.0 headers support 5 additional USB 2.0 ports
  • Ethernet
    1 x Realtek 2.5Gb Ethernet
    TUF LANGuard
  • Form Factor
    micro-ATX (9.6 inch x 8.7 inch)
  • Warranty
    1 Year Warranty
