Asus ProArt X870E-CREATOR WiFi Motherboard, AM5 Socket, ATX Form Factor, DDR5 Ram, PCIe 5.0 With SafeSlot Core+, Wi-Fi 7 & Bluetooth v5.4, USB 40Gbps, HDMI, Thunderbolt4, Marvell AQtion 10Gb/Intel 2.5Gb Ethernet With Asus LANGuard, Aura Sync, 1 Year Warranty | 90MB1IG0-M0EAY0

• CPU
  Socket: AM5, AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
• Ethernet
  1 x Marvell® AQtion 10Gb Ethernet, 1 x Intel® 2.5Gb Ethernet, ASUS LANGuard
• USB
  Rear USB (Total 11 ports): 2 x USB4 (40Gbps) Type-C, 1 x USB 20Gbps Type-C, 7 x USB 10Gbps Type-A, 1 x USB 2.0 Type-A, Front USB (Total 9 ports): 1 x USB 20Gbps connector (supports USB Type-C with up to 30W PD/QC4+), 1 x USB 5Gbps header (supports 2 x USB 5Gbps), 3 x USB 2.0 headers (support 6 x USB 2.0)
• Chipset
  AMD X870E Chipset
• Wireless
  Wi-Fi 7 (Qualcomm QCNCM865 or MediaTek MT7927), 2x2 Wi-Fi 7** (802.11be), Supports 2.4/5/6GHz frequency band, Bluetooth® v5.4
• Memory slots Support
  4 x DIMM slots, max. 256GB, DDR5, Support up to 8000+MT/s(OC)
• Internal I/O Connectors
  Cooling: 1 x CPU Fan (4-pin), 1 x CPU OPT Fan (4-pin), 1 x AIO Pump (4-pin), 5 x Chassis Fan (4-pin), Power: 1 x 24-pin ATX, 2 x 8-pin 12V CPU, Storage: 4 x M.2 (Key M), 4 x SATA 6Gb/s, USB: 1 x USB 20Gbps Type-C (supports up to 30W PD/QC4+), 1 x USB 5Gbps header (supports 2 x USB 5Gbps), 3 x USB 2.0 headers (support 6 x USB 2.0), Misc: 3 x Addressable Gen 2, 1 x Chassis Intrusion, 1 x COM, 1 x CPU Over Voltage jumper, 1 x Front Audio (F_AUDIO), 1 x System Panel (10-1 pin), 1 x Thermal Sensor
• Expansion Slots
  Expansion Slots: 2 x PCIe 5.0 x16 slots with Q-Release Slim, 1 x PCIe 4.0 x16 slot with Q-Release Slim, 1 x PCIe 4.0 x16 slot (supports x4 mode), Storage: 4 x M.2 slots, 4 x SATA 6Gb/s ports
• Graphics Device
  1 x HDMI™ 2.1 port, 2 x USB4® (40Gbps) ports support USB Type-C
• Sound
  Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC, 3 x Audio jacks
• Form Factor
  ATX, 12 x 9.6 in
• Warranty
  1 Year Warranty
