1 x 24-pin ATX main power connector,
2 x 8-pin ATX 12V power connectors,
1 x CPU fan header,
1 x water cooling CPU fan header,
3 x system fan headers,
1 x system fan/water cooling pump header,
2 x addressable LED strip headers,
2 x RGB LED strip headers,
4 x M.2 Socket 3 connectors,
4 x SATA 6Gb/s connectors,
1 x front panel header,
1 x front panel audio header,
1 x USB Type-C® header (USB 3.2 Gen 2),
1 x USB 3.2 Gen 1 header,
2 x USB 2.0/1.1 headers,
2 x Thunderbolt™ add-in card connectors,
1 x Trusted Platform Module header (GC-TPM2.0 SPI V2),
1 x reset button,
1 x Q-Flash Plus button,
1 x Clear CMOS button,
1 x reset jumper,
1 x Clear CMOS jumper,
1 x USB Type-C® port (USB 3.2 Gen 2x2),
2 x USB 3.2 Gen 2 Type-A (Red),
3 x USB 3.2 Gen 1 Type-A,
4 x USB 2.0/1.1 ports,
2 x SMA antenna connectors (2T2R),
1 x HDMI port,
1 x DisplayPort,
1 x RJ-45 port,
1 x optical S/PDIF Out connector,
2 x audio jacks
