Asus PRIME B760-Plus D4 Motherboard, LGA 1700 Socket, ATX Form Factor, DDR4 Ram, PCIe 5.0, USB 3.2 Gen 2, HDMI, DisplayPort, VGA, Realtek 2.5Gb Ethernet, Asus 5X Protection III, Aura Sync RGB Lighting, 1 Year Warranty | 90MB1CW0-M0EAY0

• CPU
  Socket: LGA 1700, Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
• Ethernet
  1 x Realtek 2.5Gb Ethernet
• USB
  Rear USB (Total 6 ports): 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 2 x USB 3.2 Gen 2 ports (2 x Type-A), 1 x USB 3.2 Gen 1 port (1 x Type-A), 2 x USB 2.0 ports (2 x Type-A), Front USB (Total 7 ports): 1 x USB 3.2 Gen 1 connector (supports USB Type-C®), 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports
• Chipset
  Intel® B760 Chipset
• Wireless
  N/A
• Memory slots Support
  4 x DIMM, Max. 128GB, DDR4, Dual Channel Memory Architecture, Supports Intel® Extreme Memory Profile (XMP)
• Internal I/O Connectors
  Cooling: 1 x CPU Fan (4-pin), 1 x AIO Pump (4-pin), 3 x Chassis Fan (4-pin), Power: 1 x 24-pin ATX, 1 x 8-pin 12V, Storage: 3 x M.2 (Key M), 4 x SATA 6Gb/s, USB: 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 1 header (supports 2x USB 3.2 Gen 1), 2 x USB 2.0 headers (supports 4x USB 2.0), Misc: 3 x Addressable Gen 2, 1 x Aura RGB, 1 x Clear CMOS, 1 x COM, 1 x Front Audio (AAFP), 1 x S/PDIF Out, 1 x SPI TPM (14-1 pin), 1 x System Panel (20-3 pin with Chassis Intrude), 1 x Thunderbolt (USB4) header
• Expansion Slots
  Expansion Slots: 1 x PCIe 5.0 x16 slot, 1 x PCIe 4.0 x16 slot (supports x4 mode), 2 x PCIe 3.0 x1 slots, Storage: 3 x M.2 slots, 4 x SATA 6Gb/s ports
• Graphics Device
  1 x DisplayPort, 1 x VGA port, 1 x HDMI™ port
• Sound
  Realtek 7.1 Surround Sound High Definition Audio CODEC, 3 x Audio jacks
• Form Factor
  ATX, 12 x 9.6 in
• Warranty
  1 Year Warranty
