Socket: LGA 1700,
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
Ethernet
Realtek® RTL8125BG 2.5G LAN
USB
1 x USB 3.2 Gen 2x2 20G (1 Type-C),
8 x USB 3.2 Gen 1 5Gbps (8 Type-A),
6 x USB 2.0
Chipset
Intel® Z790 Chipset
Wireless
Intel® Wi-Fi 6E, Bluetooth 5.3
Memory slots Support
4 DIMMs, Dual Channel DDR5-6600+MHz(OC)
Internal I/O Connectors
1 x ATX_PWR,
2 x CPU_PWR,
1 x CPU Fan,
1 x Pump Fan,
4 x System Fan,
2 x Front Panel (JFP),
1 x Chassis Intrusion (JCI),
1 x Front Audio (JAUD),
1 x RGB LED (JRGB),
1 x TPM Header (TPM 2.0),
4 x USB 2.0,
4 x USB 5Gbps Type-A
Expansion Slots
Expansion Slots:
1 x PCIe 5.0 x16 slot,
1 x PCIe 3.0 x16 slot,
3 x PCIe 3.0 x1 slots,
Storage:
2 x M.2 Gen4 x4 64Gbps slots,
4 x SATA 6Gbps ports
Graphics Device
1 x HDMI 1.4,
1 x DisplayPort 1.4
Sound
Realtek® ALC897 Codec,
7.1-Channel High Definition Audio,
Supports S/PDIF output
